| Test Parameter | Method | Unit | Specification | MSDS |
|---|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | -- | Pale Yellow,Viscous clear liquid |  |
| Solubility in Ethyl alcohol | IS 548 (part 1 :sec2).2021 | -- | Complete soluble without turbidity | |
| Color in 1” cell,(Y+5R) in Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Unit | 30 Units max | |
| Free Fatty Acid (as oleic) | IS 548 (part 1 :sec2).2021 | % | 1.0 Max | |
| Acid Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 2.0 max | |
| Moisture | IS 548 (part 1 :sec2).2021 | % | 0.50 max | |
| Insoluble Impurities | IS 548 (part 1 :sec2).2021 | % | 0.02 | |
| Specific Gravity at 30 deg C | IS 548 (part 1 :sec2).2021 | -- | 0.952 – 0.965 | |
| Refractive Index at 40 deg C | IS 548 (part 1 :sec2).2021 | -- | 1.4700 – 1.4810 | |
| Iodine Value (Wij’s method) g | IS 548 (part 1 :sec2).2021 | I2 / 100 g | 82 – 90 | |
| Saponification Value mg | IS 548 (part 1 :sec2).2021 | KOH / g | 177 – 185 | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | -- | 155 - 168 | |
| Unsaponifiable matter | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Mineral Oil test | IS 548 (part 1 :sec2).2021 | -- | Negative | |
| Viscosity | IS 548 (part 1 :sec2).2021 | poise | 6.0 – 9.0 |
| Test Parameter | Method | Unit | Specification | MSDS |
|---|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | -- | Pale Yellow,Viscous clear liquid | |
| Solubility in Ethyl alcohol | IS 548 (part 1 :sec2).2021 | -- | Complete soluble without turbidity | |
| 3 Color in 1” cell,(Y+5R) in Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Units | 2.2 Y, 0.3 R max | |
| 3 Color in 1” cell,(Y+5R) in Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Unit | 2.2 Y, 0.3 R max | |
| Color in 5.25” cell, (Y+5R) In Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Units | 20.0 Y, 2.0 R max | |
| Free Fatty Acid (as oleic) | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Acid Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 2.0 max | |
| Moisture | IS 548 (part 1 :sec2).2021 | % | 0.25 max | |
| Insoluble Impurities | IS 548 (part 1 :sec2).2021 | % | 0.02 | |
| Specific Gravity at 30 deg C | IS 548 (part 1 :sec2).2021 | -- | 0.954 – 0.960 | |
| Refractive Index at 40 deg C | IS 548 (part 1 :sec2).2021 | -- | 1.4700 – 1.4740 | |
| Iodine Value | IS 548 (part 1 :sec2).2021 | (Wij’s method) g I2 / 100 g | 82 – 90 | |
| Saponification Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 177 – 185 | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | -- | 155 - 165 | |
| Unsaponifiable matter | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Mineral Oil test | IS 548 (part 1 :sec2).2021 | -- | Negative | |
| Viscosity | IS 548 (part 1 :sec2).2021 | poise | 6.0 – 9.0 |
| Physical Properties | Method | MSDS | |
|---|---|---|---|
| Appearance malted : | Cream to white in melted condition Find clear & transparent | IS 548 (part 1 :sec2).2021 | |
| Specific Gravity @ 25°C : | 1.0-+ 02 | IS 548 (part 1 :sec2).2021 | |
| Molecular Weight : | 932 | IS 548 (part 1 :sec2).2021 | |
| Melting Ponit : | 85°C Min | IS 548 (part 1 :sec2).2021 | |
| Flash Content : | Nil | IS 548 (part 1 :sec2).2021 | |
| Flash Ponit : | 315°C (CoC) | IS 548 (part 1 :sec2).2021 | |
| Fire Ponit : | 335°C (CoC) | IS 548 (part 1 :sec2).2021 | |
| Penetration Hardness : | 2 | IS 548 (part 1 :sec2).2021 | |
| Viscosity of Melt @ 200°C : | 0.24 Paise | IS 548 (part 1 :sec2).2021 | |
| Viscosity of Melt @ 250°C : | 0.16 Paise | IS 548 (part 1 :sec2).2021 |
| Chemical Property | Method | |
|---|---|---|
| Acid Value : | 3 Max | IS 548 (part 1 :sec2).2021 |
| Acetyl Value : | 139 Min | IS 548 (part 1 :sec2).2021 |
| Hydroxyl Value : | 155 Min | IS 548 (part 1 :sec2).2021 |
| Iodine Value : | 3 Max | IS 548 (part 1 :sec2).2021 |
| Saponification Value : | 180 Min | IS 548 (part 1 :sec2).2021 |
| Colour Lovibond 5 ¼ : | 20 Yellow /2. O RED | IS 548 (part 1 :sec2).2021 |
| Test Parameter | Method | Specification | MSDS |
|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | Cremish Flakes | |
| Iodine value,gI2/100g | IS 548 (part 1 :sec2).2021 | 3 max | |
| Saponification value,mg KOH/g | IS 548 (part 1 :sec2).2021 | 178-190 | |
| Acid value,mg KOH/g | IS 548 (part 1 :sec2).2021 | 175 min | |
| Hydroxyl value mg KOH/g | IS 548 (part 1 :sec2).2021 | 155 min | |
| Melting Point,deg C | IS 548 (part 1 :sec2).2021 | 74-78 | |
| Melting Point,deg C | IS 548 (part 1 :sec2).2021 | 74-78 | |
| Color Gardner | IS 548 (part 1 :sec2).2021 | 4 max | |
| Purity by GC % | IS 548 (part 1 :sec2).2021 | 12-HST 85% min, 12-KST 2 max |
| Test Parameter | Method | Unit | Specification | MSDS |
|---|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | -- | Pale Yellow,Viscous clear liquid | |
| Solubility in Ethyl alcohol | IS 548 (part 1 :sec2).2021 | -- | Complete soluble without turbidity | |
| Color in 1” cell,(Y+5R) in Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Units | 2.2 Y, 0.3 R max | |
| Free Fatty Acid (as oleic) | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Acid Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 2.0 max | |
| Moisture | IS 548 (part 1 :sec2).2021 | % | 0.02 max | |
| Insoluble Impurities | IS 548 (part 1 :sec2).2021 | % | 0.02 | |
| Specific Gravity at 30 deg C | IS 548 (part 1 :sec2).2021 | -- | 0.954 – 0.965 | |
| Refractive Index at 40 deg C | IS 548 (part 1 :sec2).2021 | -- | 1.4700 – 1.4810 | |
| Iodine Value | IS 548 (part 1 :sec2).2021 | (Wij’s method) g I2 / 100 g | 82 – 90 | |
| Saponification Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 177 – 185 | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | -- | 160 - 168 | |
| Unsaponifiable matter | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Mineral Oil test | IS 548 (part 1 :sec2).2021 | -- | Negative | |
| Viscosity | IS 548 (part 1 :sec2).2021 | poise | 6.0 – 9.0 |
| Specification | Method | MSDS | |
|---|---|---|---|
| Appearance | Pale Yellow, Brilliantly Clear, Viscous liquid. | IS 548 (part 1 :sec2).2021 | |
| Odor | Natural characteristics | IS 548 (part 1 :sec2).2021 | |
| F.F.A. (as oleic), (%) | 0.40 Maximum. | IS 548 (part 1 :sec2).2021 | |
| Acid Value, (mg KOH/gm) Moisture, | 0.80 Maximum. | IS 548 (part 1 :sec2).2021 | |
| (K.F.), (%) | 400 PPM Maximum | IS 548 (part 1 :sec2).2021 | |
| Color, Gardner | 1 G Maximum | IS 548 (part 1 :sec2).2021 | |
| Hydroxyl Value, (mg KOH/gm) | 160 - 168 | IS 548 (part 1 :sec2).2021 | |
| Specific gravity @ 30° C (gm/ml) | 0.952 ‐ 0.965 | IS 548 (part 1 :sec2).2021 | |
| Iodine Value, (Wijs), (g I2/100g) | 82 ‐ 90 | IS 548 (part 1 :sec2).2021 | |
| Refractive index @ 25°C | 1.476 ‐ 1.487 | IS 548 (part 1 :sec2).2021 | |
| Unsaponifiable Matter, (%) | 0.80 Maximum | IS 548 (part 1 :sec2).2021 | |
| Saponification Value, (mg KOH/gm) | 177 - 187 | IS 548 (part 1 :sec2).2021 | |
| Color on Lovibond Tintometer scale in 5 ¼” Cell | Yellow – 10.0 Maximum. & Red – 1.0 Maximum | IS 548 (part 1 :sec2).2021 |
| Test Parameter | Method | Unit | Specification | MSDS |
|---|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | -- | Pale Yellow,Viscous clear liquid | |
| Solubility in Ethyl alcohol | IS 548 (part 1 :sec2).2021 | -- | Complete soluble without turbidity | |
| 3 Color in 1” cell,(Y+5R) in Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Units | 2.2 Y, 0.3 R max | |
| 3 Color in 1” cell,(Y+5R) in Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Unit | 2.2 Y, 0.3 R max | |
| Color in 5.25” cell, (Y+5R) In Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | Units | 20.0 Y, 2.0 R max | |
| Free Fatty Acid (as oleic) | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Acid Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 2.0 max | |
| Moisture | IS 548 (part 1 :sec2).2021 | % | 0.25 max | |
| Insoluble Impurities | IS 548 (part 1 :sec2).2021 | % | 0.02 | |
| Specific Gravity at 30 deg C | IS 548 (part 1 :sec2).2021 | -- | 0.954 – 0.960 | |
| Refractive Index at 40 deg C | IS 548 (part 1 :sec2).2021 | -- | 1.4700 – 1.4740 | |
| Iodine Value | IS 548 (part 1 :sec2).2021 | (Wij’s method) g I2 / 100 g | 82 – 90 | |
| Saponification Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 177 – 185 | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | -- | 155 - 165 | |
| Unsaponifiable matter | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Mineral Oil test | IS 548 (part 1 :sec2).2021 | -- | Negative | |
| Viscosity | IS 548 (part 1 :sec2).2021 | poise | 6.0 – 9.0 |
| Test Parameter | Method | Unit | Specification | MSDS |
|---|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | -- | Pale Yellow,Viscous clear liquid | |
| Solubility in Ethyl alcohol | IS 548 (part 1 :sec2).2021 | -- | Complete soluble without turbidity | |
| Color in 5.25” cell In Lovibond Tint meter | IS 548 (part 1 :sec2).2021 | (Y+5R) Units | 10.0 Y, 1.0 R max | |
| Free Fatty Acid (as oleic) | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Acid Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 2.0 max | |
| Moisture | IS 548 (part 1 :sec2).2021 | % | 0.25 max | |
| Insoluble Impurities | IS 548 (part 1 :sec2).2021 | % | 0.02 | |
| Specific Gravity | IS 548 (part 1 :sec2).2021 | @30 deg C | 0.954 – 0.969 | |
| Refractive Index | IS 548 (part 1 :sec2).2021 | @40 deg C | 1.4770 – 1.4810 | |
| Iodine Value | IS 548 (part 1 :sec2).2021 | (Wij’s method) g I2/100 g | 82 – 90 | |
| Saponification Value | IS 548 (part 1 :sec2).2021 | mg KOH / g | 175 – 185 | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | --- | 160 - 168 | |
| Unsaponifiable matter | IS 548 (part 1 :sec2).2021 | % | 1.0 max | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | -- | 155 - 165 | |
| Mineral Oil test | IS 548 (part 1 :sec2).2021 | -- | Negative | |
| Viscosity | IS 548 (part 1 :sec2).2021 | poise | 6.0 – 9.0 |
| Test Parameter | Method | Specification | MSDS |
|---|---|---|---|
| Appearance | IS 548 (part 1 :sec2).2021 | Viscous liquid | |
| Color, Gardner Scale | IS 548 (part 1 :sec2).2021 | 6 Max | |
| Acid Value | IS 548 (part 1 :sec2).2021 | 5 Max | |
| Iodine Value | IS 548 (part 1 :sec2).2021 | 123 Min | |
| Hydroxyl Value | IS 548 (part 1 :sec2).2021 | 25 Max | |
| Saponification Value | IS 548 (part 1 :sec2).2021 | 185 – 194 |
